Description

EOTech XPS2-2 — Compact Holographic Sight with 2-Dot Ballistic Reticle

Name: Red Dot EOTECH XPS2-2 — Compact Holographic Sight with 2-Dot Ballistic Reticle
Brand: EOTECH
Price: 799 CHF
Availability: InStock

Overview

The EOTech XPS2-2 carries the ultra-compact chassis of the famous XPS2 — 96.5 mm long, 255 g, EOTech's shortest and lightest HWS — but integrates a specific 68 MOA + 1 MOA + 2 ballistic dots reticle. The result: 4 usable aiming points for engaging targets quickly at close, medium AND long range without changing optics or adding a magnifier.

The 2-Dot reticle is calibrated for the US military reference caliber: .223 Remington / 5.56 NATO, 62-grain projectile, 2,900 fps velocity (typical of 14.5-16" AR-15 barrels). The center dot handles standard zero (typically 50/200 yards), and the 2 secondary dots below the center dot compensate for bullet drop at extended ranges — allowing engagement out to roughly 500 meters without mental hold-over.

This configuration specifically targets the AR-15 shooter in 5.56 NATO who wants short / medium / long-range versatility on a single 1x optic, without the weight or complexity of a magnifier or LPVO. Ideal for dynamic sport shooting on long-range stages, patrol rifle training, or 3-Gun competition where agility is paramount.

Technical Specifications

Optic type: 1x holographic sight (HWS — Holographic Weapon Sight)
Magnification: 1x (no magnification)
Reticle: 68 MOA (enclosure ring) + 1 MOA (center dot) + 2 ballistic secondary dots (drop compensation) — red reticle
Usable aiming points: 4 (center dot + 3 ballistic holds)
Ballistic calibration: .223 Remington / 5.56 NATO, 62 grains, 2,900 fps velocity
Viewing window: 30.5 x 21.6 mm
Eye relief: Unlimited
Parallax: Parallax-free
Front window: Solid glass
Rear window: Shatter-resistant laminate
Optical coating: Anti-glare multi-coating
Brightness settings: 20 daylight levels, rear buttons
Night-vision compatibility: No
Power source: 1x CR123 3V lithium battery (included)
Battery life: 1,000 continuous hours at nominal setting 12
Auto shut-off: Programmable
Mount: Integrated, Weaver 1" or Picatinny MIL-STD-1913, tool-less cross-bolt (hand-tightened)
Windage/elevation adjustment: 0.5 MOA per click (1/2" at 100 yards)
Water resistant: to 3 m (10 ft), fog-proof internal optics
Operating temperature: -40°C to +60°C (-40°F to 140°F)
Length: 96.5 mm (3.8")
Width: 53.3 mm (2.1")
Height: 63.5 mm (2.5")
Weight: 255 g (9.0 oz)
Finish: Matte black, CNC-machined anodized aluminum
Manufacturer warranty: 10 years
Made in USA — Michigan

Key Benefits

Unique EOTech 2-Dot ballistic reticle: 4 usable aiming points on a single 1x optic — engage close, medium AND long-range targets (out to ~500 m) without a magnifier or mental hold-over calculation.
.223 / 5.56 NATO 62 gr calibration: perfectly suited to AR-15 platforms with 14.5-16" barrels — the reference caliber for patrol rifle and modern sport carbine shooting.
The shortest EOTech HWS: at 96.5 mm long and just 255 g, it frees maximum rail space — perfect for magnifier or BUIS combos.
68 MOA enclosure ring: preserves all the acquisition speed of the classic EOTech reticle for short engagements and CQB.
True holographic technology: not an LED red dot — genuine EOTech holographic projection, clear and bright sight picture even with a partially obscured window.
CR123 battery life: 1,000 continuous hours on a single CR123 lithium cell.
Tool-less cross-bolt mount: hand-tightened, quick installation on any Weaver 1" or Picatinny MIL-STD-1913 rail.
Compatible with EOTech G33/G43 magnifiers: for shooters who also want optical precision at 300-500 m with 3x magnification.
EOTech ruggedness: CNC-machined aluminum housing, -40°C to +60°C operational range, 3 m water-resistant.
10-year warranty: EOTech manufacturer commitment with recognized after-sales support.

Use Cases & Context

Long-range sport shooting with 5.56 rifles: engage 50 to 500 m on a single 1x optic without slowing down at close range. Ideal for 3-Gun stages with distant targets.
Patrol rifle / service carbine training: AR-15 platform in .223/5.56 — the 62 gr @ 2,900 fps calibration matches reference M855/M193 loadings.
Tactical shooting and CQB: the 68 MOA ring keeps all its acquisition speed for close engagements.
3-Gun competition: rare versatility — a single 1x sight that handles close targets AND 300-500 m engagements without optic switching.
Sport hunting for small game / predators at mid range: the 2 secondary dots ease engagement of distant targets without magnification.
Optional magnifier combo: paired with EOTech G33 or G43, you get a 1x/3x flip-to-side configuration that fully exploits the reticle's ballistic holds.
Short AND standard AR-15 rifles: MK18, DDM4 V7, DDM4 V7 K, 10.3-16" platforms — calibration remains optimal on 14.5-16" barrels.
Recreation and collection: rare and differentiating reticle variant in the EOTech ecosystem.
